 Planning, Plotting, And Scheming- Name TBA

Go down
Go to page : 1, 2, 3, 4, 5, 6, 7, 8  Next
AuthorMessage
Doc Sprocket
Administrator
Administrator
avatar

Age : 45
Join date : 2013-04-21
Posts : 2910
Forum Rep : 15
Location : Ontario Canada

PostSubject: Planning, Plotting, And Scheming- Name TBA   Wed Sep 18, 2013 2:55 pm

Well- I've been thinking about and talking about it. Time to take the first step- eyeballing and documenting. First- The starting point. It's a long-dead 1970-something (unsure as of yet) Bolens garden tractor. It's a hydro, and everything about it screams "BEEF!". The frame is quite stout, the front axle is a heavy cast-iron bugger, the hydro transaxle is also cast iron and huge. As big and badass as the hydro is, it's leaving. It did work when parked but I have a driveline idea I want to explore.

The original engine is long gone, a previous owner replaced it with a 18hp Vanny horizontal, which has been sitting in my garage. Needed a carb job when parked.

The plan: Another Mobile Utility and Light Extrication, bigger, badder, better. Standard features will include MULE's usuals- Bigger more aggressive tires, onboard air compressor and battery boost, winch, tool and fuel storage, etc. What's new? Aside from simply "bigger", the driveline is going to take a major left-hand turn. Briggs Vanny V-Twin 18hp horizontal, Comet 40 CVT, Race-Prepped Peerless 700 transmission, Disc Brakes, Live (go kart) axle. Ultimately, I'd like to make it a tandem, but we will see. I'd like to build a pickup-style bed, and an A-Frame or some other rear load-lifting apparatus. Not shown is the hood and seat (I have them) and the rear fender unit which I reconfigured to go on General Mayhem. Here's the starting point-

****************************************EDIT 03/11/14***********************************
I've decided The John Deere 112 will become MULEII. This project WILL continue, under a different name to be announced later





_______________________________________________
***Get YOUR official "Doc Locked, And Ready To Rock!" Stickers by clicking here!***
***Official Sprocket's Garage vinyl graphics and tees for sale HERE!***

Put down the wrench, and come out with your hands up!-Doc "Tranny Crusher" Sprocket, ATLTF Forum Admin, Thinkerer and Tinkerer, and all-around good dood. Wink

Gen. Mayhem- http://www.atltf.com/t2597-general-mayhem-race-tractor
MULE- http://www.atltf.com/t2153-lawn-boy-utltv
MULEII- http://www.atltf.com/t3328-1970-john-deere-112-the-beginnings-of-mule-ii
MULEIII http://www.atltf.com/t4263-mule3-brainstorming-ideas-etc#58287
Wrench, Wheel, Wreck, Repeat...


Last edited by Doc Sprocket on Tue Mar 11, 2014 8:30 am; edited 4 times in total
