PostSubject: MTD off-road romper build.   Mon Mar 18, 2013 5:43 pm



well I think I uploaded it right. Anyways, heres my first tractor. Ive always wanted to tinker with something, so here it is. a cheap mtd for free, and I didn't have any intentions other than mods and beating on it. I picked it up last fall, and did the following things.



First I took the deck off.


took the front clip off to clean everything. put the grille back on.


Being a 1:1 off road buggy, truggy, jeep fan I am kinda a flex freak haha. Very Happy


I headed out for my first ever romp with my best friend and his craftsman. still no seat if youre wondering, it was in terrible condition.


Hood mod because im a 1:1 offroad freak as I said haha.



Decided to do a front tire mod with a small, almost to small, snowblower tires. (toro)


One of the bigger must-have mods. I mocked up a beefy front bumper.


Me burning it in. You will see it in other pictures of the mower, as a whole.


Decided I needed a new pipe, so bought some 90's and welded them on the cut pipe.


Then I made a hanger bracket for it, and painted it. I wish I got a solid pic of the side pipe. ill do that soon guys Very Happy


Well this will have to do, and yea, haha, it works great!!! Cool


AAAAAAAAAAAAAAAAAnd this is where I basically screw it all up. I had a Honda hawk cb400 that I was eager to drop in. I tear the hole thing apart in preparation on the new motor. I was planning on a atv rear axle and later realized that I was way over my head.


But hey, sometimes you gotta dream Very Happy


Tore it down to the chassis and it sat over January and febuary, until I got my sane, and motivation back.
